Precision Zemic Load Cell for Real-Time Weighing Feedback
A single-point load cell converts a force such as tension, compression, pressure or torque into a measurable standard signal (electrical, pneumatic, hydraulic or mechanical displacement indicator). It is a force sensor. As the force applied to the load cell increases, the signal changes proportionally. The most common types of load cells used in industrial applications are pneumatic, hydraulic and strain gauge types.
| SCALE SPECIFICATIONS | ||
| Rated Capacity | 100/150/200/250 /300/500/800kg | |
| Accuracy Class | C3 | |
| Rated Output | 2.0±0.2mV/V | |
| Temperature Effect on Zero | ±0.02%F.S/10ºC | |
| Temperature Effect on Sensitity | ±0.02%F.S/10ºC | |
| Creep (30 min) | ±0.02%F.S | |
| Input Resistance | 385±10Ω | |
| Output Resistance | 350±2Ω | |
| Operating Temperature Range | -30ºC ~ +70ºC | |
| Application For | Waterproof bench | |
| Safe Overload | 150%F.S | |
| Destructive Load | 300%F.S | |
| Excitation Recommend | 4~12V DC, max 15V DC | |
| Construction | alloy steel or stainless steel | |
| Protection Class | IP67 | |
| Cable length | 4 core cable standard lengths | 2m(100~800kg) |
| diameter | Ø 5 | |
| option | customized cable length | |
HIGH ACCURACY AND RELIABILITY:
This Single Point Load Cell provides precise measurements, ensuring reliable results in a wide range of applications. Its combined error is suitable for demanding industries.
DURABLE CONSTRUCTION:
The Single Point Load Cell is made of high-quality alloy steel, which provides excellent durability and corrosion resistance.
DURABLE CONSTRUCTION:
The Single Point Load Cell is made of high-quality alloy steel, which provides excellent durability and corrosion resistance.
EASY INSTALLATION:
The ease of installing a Single Point Load Cell affects overall productivity. Engineers will be more productive if they can easily install certain models without making extensive infrastructure changes or modifications. Furthermore, the existing calibration procedures simplify user maintenance and provide adequate uptime from the first day of operation.
USER-FRIENDLY OUTPUT:
The device has analog outputs that can be easily integrated with various systems according to user requirements.
